Dormakaba GSR-EMR XEA BG Mounting Instructions

10
TS 98 XEA
mit Brandschutzplatte
with fire protection plate
2021-10
dormakaba Montageanleitung
Mounting instructions
TS 98 XEA einstellen/Set TS 98 XEA
WN 060289 45532
70° – 15°
EN 1 – 6 ≤ 10 Nm
15° – 0°
7° – 0°
Max. – 70°
60° – 90°
EN 1 – 6
X
X [mm] EN
< 750 1
750 – 850 2
850 – 950 3
950 – 1100 4
1100 – 1250 5
1250 – 1400 6
X [mm] EN
850 –
1400
3 – 6
DIN 18040
X [mm]
750 – 1250
10 TS 98 XEA einstellen/Set TS 98 XEA
