REPAIR PARTS:
3
85
011031B BSP
21
194612
194615 (2x)
194550
1
011172
9
193641
194605
86
34
88
011031 NPT
194610
40
011876
011879T 10%
Reference # Part # Description
1 194610 Upper Body
34 193641 Cotter Ring
3 194605 Mixing Chamber Gasket
9 011876 Piston Assembly
011879T Piston Assembly 10%
21 011172 Shaft Assembly
40 011031 Lower Body NPT 1"
011031B Lower Body BSP 1"
85 194612 Upper Shaft Pin
86 194550 Cap
88 194615 Non bypass plug
11
