LOWER END INJECTOR & WEAR PARTS KITS 0.4%:
Kit A – Wear Parts Kit (dosage piston/shaft assy, oring) 011851PV 17, 51
Kit C – Wear Parts Kit (Kit A, inner cylinder, oring) 011854PV 17, 51, 68, 81
Kit D – Suction Tube Fitting Assy (poppet, nut, washer,
oring, spring, tting)
011463V 10, 11, 12, 13, 71, 80
Kit E – Wear Parts Kit (Kits C & D, inner cylinder (2nd
inner cylinder), shaft, pin, gasket)
011834PV 7, 10, 11, 12, 13, 16, 17, 51, 64, 68,
71, 80, 81
Kit F – Lower End Cylinder Kit (inner & outer cylinder,
ratio adjuster, oring, retainer clip, pin, gasket)
011960PV 7, 16, 61, 64, 65, 66, 67, 68, 79, 81
Kit G - Lower End Kit, complete (Kit E, outer cylinder,
ratio adjuster, oring, retainer clip, pin, retainer, lter,
solution tube)
011843MV 7, 10, 11, 12, 13, 15, 16, 17, 25, 27,
51, 61, 64, 65, 66, 67, 68, 71, 79, 80,
81
Kit H – Motor Piston Assy (upper end kit) 011863 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex
caps & nuts)
011432 56, 57, 58
Manual Reference Part # Description of Part
7 194404P Cylinder, inner
10 194418H Spring
11 194417 Fitting, suction tube, ¼”
12 212120
*Must specify material
O-ring
13 011453A Poppet, check w/washer
15 194004 Seal retainer, o-ring
16 010016
*Must specify material
Gasket, inlet/outlet and cylinder
17 212005
*Must specify material
O-ring
25 010025 Suction tube, ¼” x 5’
27 003067 Filter and foot valve, suction tube, ¼” ID
51 011812
*Must specify material
Shaft, Assy with dosage piston
61 194406P Ratio adjustment sleeve
64 212017
*Must specify material
O-ring, inner cylinder, lower end
65 194310D Pin, upper interlock
66 212025
*Must specify material
O-ring, outer cylinder, lower end
67 011919P Cylinder, outer
68 011458 Cylinder, inner for #7
71 194414 Nut, suction tube tting
79 194410SS Pin, narrow interlock
80 194415 Twistlock
81 212516
*Must specify material
O-ring, inner cylinder (#68)
12
