Dosmatic SUPERDOS 20 - Wear Parts Kits

LOWER END INJECTOR & WEAR PARTS KITS 2.5%:
Description of Kit Part # Manual Reference
Kit A – Wear Parts Kit (dosage piston and oring) 011850V 17, 44
Kit B – Wear Parts Kit (Kit A, & shaft) 011945V 17, 44, 51
Kit C – Wear Parts Kit (Kit A, inner cylinder and o-ring) 011850CV 7, 17, 44, 64
Kit D – Suction Tube Fitting Assy (poppet, nut, washer, o-ring,
spring, tting)
011463V 10, 11, 12, 13, 71, 80
Kit E – Wear Parts Kit (Kits C & D, shaft, pin, gasket) 011833PV 7, 10, 11, 12, 13, 16, 17, 44, 51,
64, 71, 80
Kit F – Lower End Cylinder Kit (inner & outer cylinder, ratio
adjuster, o-rings, retainer clip, pin, gasket)
011961V 7, 16, 61, 64, 65, 66, 67, 79
Kit G - Lower End Kit, complete (Kit E, outer cylinder, ratio ad-
juster, o-rings, retainer clips, pins, retainer, lter, solution tube)
011843PV 7, 10, 11, 12, 13, 14, 15, 16, 17,
25, 27, 44, 51, 61, 64, 65, 66,
67, 71, 79, 80
Kit H – Motor Piston Assy (upper end kit) 011863 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex caps &
nuts)
011432 56, 57, 58
Manual Reference Part # Description of Part
7 194404P Cylinder, inner
10 194418H Spring
11 194417 Fitting, suction tube, 1/4”
12 212120
*Must specify material
O-ring
13 011453A Poppet, check w/washer
14 212005
*Must specify material
O-ring
15 194004 Seal retainer, o-ring
16 010016
*Must specify material
Gasket, inlet/outlet and cylinder
17 212005
*Must specify material
O-ring
25 010025 Suction tube, ¼” x 5’
27 011017 Filter, for suction tube, ¼” ID
44 010044P Dosage Piston
51 194301F Shaft, with ears
61 194406P Ratio adjustment sleeve
64 212017
*Must specify material
O-ring, inner cylinder, lower end
65 194310D Pin, upper interlock
66 212025
*Must specify material
O-ring, outer cylinder, lower end
67 194407P Cylinder, outer
71 194414 Nut, suction tube tting
79 194410SS Pin, narrow interlock
80 194415 Twistlock
