Dosmatic SUPERDOS 20 - Page 18

LOWER END INJECTOR & WEAR PARTS KITS 10%:
Description of Kit Part # Manual Reference
Kit B – Wear Parts Kit (Hose Kit) 011849M 60
Kit H – Motor Piston Assy 011879T 9
Kit M – Mounting Bracket Kit (mounting bracket, 4 hex caps & nuts) 011432 56, 57, 58
Manual Reference Part # Description of Part
7 011921P Cylinder, inner
15 194004 Seal retainer, o-ring
17 212005
*Must specify material
O-ring
44 194909 Dosage Piston
51 011908 Shaft, stainless steel
61 194831 Cylinder, outer
66 212402
*Must specify material
O-ring, outer cylinder, lower end
68 212002
*Must specify material
O-ring, cylinder adapter, lower end
72 194830 Adapter
73 194833 Dosage piston guide
93 193003 Capscrew 10-32 x 1/2” SS hex
92 195861 Shaft Cap
79 195911 Ratio Locking Pin
94 212012
*Must specify material
O-ring, outer cylinder
91 212518
*Must specify material
O-ring, dosage piston guide
53 194344 Klipring
95 212007
*Must specify material
O-ring, dosage piston guide
60 011849M Hose kit
