avoid strong light source
2. Re-adjust UV sensor
Left Counting
1.Remove the banknote and clear away the dust.
2.Re-adjust counting IR sensor
3.Replace left/right counting receiving tube
Right Counting
Left2 Counting SENSOR
Right2 Counting SENSOR
Left CIS IR
1. Remove the banknote and clear away the dust
2. Replace the counting IR tube.
Right CIS IR
Rotate Speed Sensor
1. Clean away the dust and rotate speed sensor
2. Replace rotate speed sensor
3. Replace main motor
4. Replace main board
Rotate2 Speed Sensor
1.Clean away the dust and rotate speed sensor
2.Replace rotate speed sensor 2
3.Replace main motor
4. Replace main board
CIS Sensor 0
CIS Sensor 1
CIS Sensor 2
1. Clean away the dust
2. Replace CIS sensor
BIS TOP
1.Adjustment of the Commutator position
2.Detect gap of the reject pocket. Acceptable
value: 0.9~1.3MM
BIS BTT
BIS BOTTOM
BIS TTB
AD ERROR
1.Power off and restart the machine.
2. Replace main board
BRAKE ERROR
1. Replace the motor control board
2. Replace the feeding motor
Auto Adjust Ir Clean Counting Sensor
1. Clean away the dust
2. Replace the counting IR sensor
(MG8)
170(MG0)
(MG1)
Replace magnetic board on the left
