Application
Mode
checking
Parallel or single
application mode
checking success
SOC Display
★
Blink 5 times
Waiting for parallel
connection of PACK
to power circuit
SOC Display
★
1Hz
Fault
Three-Level Cell
Over Voltage
/ / / ● ●
Three-Level Cell
Under Voltage
/ / ● / ●
Three-Level Over
Temperature
/ / ● ● ●
Three-Level Under
Temperature
/ ● / / ●
Three -Level Over
Current
(charge or discharge)
/ ● / ● ●
Three -Level Under
SOH
/ ● ● / ●
Internal
communication
/ ● ● ● ●
External
communication
● / / / ●
Parallel ID coding
failure
● / / ● ●
FUSE fault ● / ● / ●
Parallel connection
failure
● / ● ● ●
Reserved ● ● / / ●
Reserved ● ● / ● ●
Reserved ● ● ● / ●
BMS fault ● ● ● ● ●
