C-19
BTF010-60 [LIVRET].doc 02/10
SECTION C:
VEGETABLE CUTTER AND MEAT GRINDER
COUPE-LÉGUMES ET HACHOIR À VIANDE
INSTALLATION AND USE OF VEGETABLE SLICER AND MEAT
GRINDER
Insert the attachment with a slight twist to the left so that the stop stud of the attachment is tight
against the side of the hole in the mixer. Press ( I ) button to start the appliance.
WORKING OPERATION FOR THE HUB ATTACHMENT
ADAPTER
Vegetable slicer speed: 250 rpm.
Insert the vegetable slicer into the hub adapter and tight the screw on the hub adapter to prevent the vegetable
slicer from moving. To activate the vegetable slicer, turn on the main switch to the position ( I ), then press on
the green button ON/OFF switch to start the slicer. To stop the vegetable slicer, press the red button ON/OFF
switch to stop the slicer. (see fig. C-19.1)
(ON/OFF switch) (Vegetable slicer)
(Hub attachment) (Hub adapter screw)
• (Main switch) Fig. C-19.1 Fig. .C-19.2
