E15
5/16
17
14
13
11
9
8
7
5
2
3
4
1
6
10
12
10
15 16
THIS SECTION IS ONLY
USED ON CA12 & CAOP12
X/X ±1/64"
X.X
X.XXX
X.XX
±0.002
±0.005
±0.01
1
ÉTAIT QUE120
17/10/96
2
ÉLIMINER
CACHE POUSSIÈRE
17/08/00
3
ÉTAIT 50099040
DEVIENT STB200
06/05/2
CA_0055 1 PL. 27 X 3 1/2 X 1/4 1
QTÉ
DESCRIPTIONNOCODE
ROTATING RACK SYSTEM
10/11/94 B. GILBERT
1 : 3 1 CA
50099050
QURB100 2 FLANGE BEARING
1
QUP110 3 PULLEY 11" 1
STB200 4 MICROSWITCH ARM
1
50099022 5 BUSHING 1
50099021 6 UPPER SUPPORT
1
7 TUBE 2 X 1 X 1/8 X 39 1/4 1
50099020 8 UPPER SHAFT
1
50099001 9 CENTER SHAFT 1
50099004 10 CENTER SUPPORT
2
50099006 11 CENTER BUSHING GUIDE 1
50099007 12 CENTER BUSHING
1
50099002 13 BOTTOM CENTER SHAFT 1
50099032 14A BOTTOM SHAF (SHORT) 1
50099033 14B BOTTOM SHAFT (LONG)
1
QURB20 15 KL44610 (SEAT) 1
QURB40 16 KL44643 (BEARING)
1
50099030 17 BOTTOM SUPPORT 1
{
50099023
50099003
{
CA6 & CAOP6
CA12 & CAOP12
1
3
To Next Page
