SROXE Touch Screen.doc 02-2020
INSTALLATION WARNINGS
POWER FAILURE WARNING
WHEN YOU HAVE A POWER FAILURE, SHUT OFF THE OVEN POWER SWITCH TO
PROTECT THE ELECTRONIC COMPONENTS WHEN THE POWER COMES BACK.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY APPLIANCE.
INSTALLATION AND SERVICE
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
Installation and service must be done by specialised technicians. Contact a certified electrician and
plumber for set up.
The oven must be connected to the utility and electrically grounded in conformity to the effective local
regulations. If these are not established, the oven must be connected according to the Canadian
Electrical Code (CSA-C22.1-XX) or National Electrical Code (NFPA 70-XX). Refer to last edition
year for XX. Installation must also allow proper access for service (24 inches each side and back).
The ovens must be installed with proper ventilation:
• The Eyebrow hood supplied with the oven. The (10”diameter for SRO2E) and (8”diameter for
SRO1E) connection collar requires a minimum of 900 CFM at 0.6inW.C. Pressure drop through
hood. Customer to supply duct and ventilator fan per local code. Airflow proving switch is factory
installed and integrated with heating system operation. Oven provided relay with max. 10.0 amp
1/2H.P. @ 120V output for fan operation. Ventilator fan is required. Consult local authorities to
determine whether Type 1 (grease) or Type 2 (vapor) duct will be required.
Make sure that provision for adequate air supply is provided for the operation of the oven.
The ovens must be installed with a proper ventilation according with the local building code.
