Mach LED 150F / 150 / 150FP
59320002 Edition 12 08.08.2018 / Bak We page 10/26
3.6 Danger of collision while positioning
the lights
During positioning, eventual collisions between
the lights, spring arms and other devices must be
avoided.
Cover parts can get loose and fall down.
3.7 Addition to positioning the lamp
When the spring arm and extension arm are in a
180° position, the lamp head cannot be moved in the
direction of the suspension axis.
A repeated force of > 25 N (according to EN 60601-
2-41) at this angle can lead to damage.
This applies for all ceiling and wall mounted lamps
(example in picture).
In order to be able to move the lamp in the direction
of its suspension axis, the angle between the exten-
sion arm and spring arm must be < 180°.
