Dr. Mach LED 150F - Technical Data; 7.1 Technical Specifications

Mach LED 150F / 150 / 150FP
59320002 Edition 12 08.08.2018 / Bak We page 16/26
7. Data
ED Mach M3 LED
7.1 Technical data
Mach LED 150F Mach LED 150 Mach LED 150FP
Central light intensity
at a distance of 1 meter
110.000 Lux 110.000 Lux 130.000 Lux
Light field diameter d
10
187 mm 200 mm 172 mm
Light field diameter d
50
96 mm 113 mm 90 mm
Light intensity with one shadower 0 % 0 % 0 %
Light intensity with two shadowers 55 % 50 % 54 %
Light intensity on the ground of a
normed tube
100 % 100 % 100 %
Light intensity on the ground of a
normed tube with one shadower
0 % 0 % 0 %
Light intensity on the ground of a
normed tube with two shadowers
55 % 50 % 54 %
Illumination depth 20% 1800 mm 1780 mm 1800 mm
Illumination depth 60% 900 mm 800 mm 840 mm
Colour rendering index R
a
96 96 96
Colour rendering index R
9
94 94 94
Max. radiation in field
in a distance of 1 meter
379 W/m² 376 W/m² 459 W/m
2
Max. radiation in field
in a distance of 0,85 meters
454 W/m² 460 W/m² 541 W/m²
Focusable
light field size
18-25 cm 19 cm (fixed focus) 17-24 cm
Colour temperature (Kelvin) 4300 K* 4300 K* 4300 K*
Electronic light intensity control
at the light head (standard)
50-100 % 50-100 % 50-100 %
Temperature increase
in head area
0,5 °C 0,5 °C 0,5 °C
Number of LED’s 26 26 26
Life span of LED’s 50.000 h 50.000 h 50.000 h
Working distance 70-140 cm 70-140 cm 70-140 cm
Diameter of the light head 40 cm 40 cm 40 cm
Height adjustment 118 cm 118 cm 118 cm
*Surcharge for a colour temperature of 4500 Kelvin.
Remark:
The technical data are subject to fluctuations. Due to manufacturing reasons the real values can slightly differ from the
data mentioned above.
The values for R
a
and R
9
can differ with approx ± 5%.
The values for the colour temperature can differ with approx ± 200K.
