DR 10 HP CHIPPER - Chapter 7; Parts Lists, Schematic Diagrams and Warranty; Parts List - DR 10 HP CHIPPER

42 DR
®
10 HP CHIPPER
CHAPTER 7
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - DR 10 HP CHIPPER
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 16193 Engine, 10 HP Briggs & Stratton Intek
02 15979 Bolt, 5/16"-18 x 1-3/4", HHCS
03 20881 Grip, Handle, 1" ID x 5" Long (Black)
04 13443 Bolt, 5/16"-18 x 1-1/2", HHCS
05 20741 Brace, Handle, LH (Kit)
06 14605 Bolt, 5/16"-18 x 1", HHCS
07 18584 Tensioner, Belt
08 14313 Nut, Lock, Nylon, 5/16"-18
09 14515 Washer, Flat, 5/16", USS, Plated
10 21649 Foot, Front
11 20741 Brace, Handle, RH (Kit)
12 19499 Bracket, Mounting, Belt Guard
(Engine Base)
13 21650 Rivet, Blind, 3/16" Dia., #68, Alum.
14 16973 Axle, 5/8" x 28-1/4"
15 18586 Bracket, Axle, Universal
16 18617 Spacer, 7/8"
17 15465 Wheel, Pneumatic, 4.10/3.50" x 4"
18 18322 Shim, 1.500" x 1.015" x .125"
19 15488 Cap, Push
Ref# Part# Description
20 14075 Clutch Assembly, 1" Bore
21 14229 Key, 1/4" x 1/4" x 1-1/4"
22 16208 Washer, Flat, 3/8"
23 21651 Washer, Lock, Split, 3/8"
24 14445 Bolt, 3/8"-24 x 1-1/4", HHCS, GR 8
25 14606 Set Screw, 5/16"-18 x 5/16"
26 14231 Pulley
27 20851 Belt Guard Assembly
28 15511 Washer, Lock, Split, 5/16"
29 14071 Belt, Drive, 5H570
30 20242 Frame
31 18589 U-Nut, 5/16"-18
32 21652 Bracket, Mounting, Belt Guard
(Forward)
33 15539 Bolt, 5/16"-18 x 4", HHCS
34 14843 Deflector
35 21661 Chipper, C10
36 19704 Nipple, Galvanized
37 19703 Coupling
38 19425 Oil Drain
