28 PREMIER DR
®
FIELD AND BRUSH MOWER
Parts List – ENGINE AND CLUTCH ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 256401 Engine, 12.5Hp, B&S m/s IntekVert
2 110761 Nut, Nylon Lock, 5/16-18
3 256411 Wire Harness, 12.5 B&S
4 110691 Nut, Finish, 5/16-18, zp
5 247271 Frame, Rear
6 150451 Bolt, HCS, 5/16-18 x 1-3/4, Gr5, zp
7 112371 Washer, Flat, 10-24, USS
8 101811 Washer, Split Lock, 1/4, zp
9 111871 Spacer, .25 ID x .375OD x 1L
10 101451 Bolt, HCS, 1/4-20 x 1-1/2, Gr2, zp
11 106361 Key, Square, .250 x 2.25 L
12 191241 Clutch, Electric, 75ft-lb, 3.86 amp
13 222521 Washer, Split, 7/16, Gr8
Ref# Part# Description
14 223241 Bolt, HCS, 7/16-20 x 2.75, Gr8, yzp
15 191301 Washer, Flat, .469ID x 1.62OD, .25L, Gr5
16 191211 Pulley, V-belt, 2.75"
17 123361 Bolt, HCS, 5/16-18 x 1-1/4, Gr5, zp
18 222451 Bolt, HCS, 7/16-20 x 2.75, Gr8, yzp
19 136831 Label, Caution, Hot Surface
20 127811 Label, Warning, Add Oil
21 157301 Bolt, HCS, 1/4-20 X 3/4, Gr5 zp
22 257111 Bracket Assembly, Clutch
23 110731 Nut, Nylon Lock, 1/4-20
24 118731 Nut, Nylon Lock, 10-24
25 175521 Eyebolt, 10-24 X 1/2"
26 150501 Spring, Extension, .438" OD X 2.5" FL
