DR PRO 26 User Manual

18 DR
®
FIELD and BRUSH MOWER
3. Rotate the Blade Pulley as you roll the belt off (Figure 26).
4. Push the belt in toward the Power Unit and the belt will fall off the Clutch
Pulley (Figure 27).
5. Pull the belt toward the deck to remove the Belt entirely.
6. Remove the Collar and Detent pin (Figure 28).
7. Shift the Wheel Speed Lever into Neutral.
8. Pull the Power unit back to release the Power Unit Pin out of the Deck Pivot
Bracket.
Cold Weather Operation
At temperatures below 30°F and a high dew point, the DR FIELD and BRUSH
MOWER Engine may experience icing of the carburetor and/or the crankcase
breather system. DR Power Equipment offers an optional Engine cover to
prevent icing in these weather conditions. You can purchase the cover through
DR Power Equipment by visiting our website at www.DRpower.com. Please
have your DR FIELD and BRUSH MOWER Model# and Serial# at hand when
the call is placed.
Clutch
Pulley
Figure 27
Belt
Collar
Figure 28
Detent Pin
Power
Unit Pin
Deck
Bracket
Blade
Pulley
Belt
Figure 26

DR PRO 26 Specifications

General

Cutting Width	26 inches
Start Type	Recoil
Drive Type	Self-Propelled
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Fuel Capacity	1.5 liters
Deck Material	Steel
Type	Walk-behind
Engine Type	4-cycle
Fuel Tank Capacity	1.5 liters
