28 DR
®
FIELD and BRUSH MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List - Handlebar Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 139051 Cable, Throttle, 50"
353171 Cable, Throttle, 61" (10.5hp only)
2 352831 Tank, Gas, Assembly, EPA/CARB
3 344321 Bracket, Battery
4 344431 Strap, Tank
5 333321 Nut, Nylon Lock, Flanged, 5/16-18
6 385301 Carbon Canister, 300cc, 3/16" Ports
7 242301 Strap, Battery
8 134471 Battery, 12v, 9Ah
9 312831 Nut, Lock, 1/4-20, Serrated Flange
10 350331 Bolt, Carr, 5/16-18 X 1.75", GR5, ZP
11 127971 Cable Tie, 17", # 50
12 351151 Cable, Brake
13 302971 Lever, Brake, W/O Hardware
14 112141 Cable Tie, 7-1/2" Long
15 352811 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X
3/4", GR5, ZP
16 359831 Harness, Wire, ES, B&S
359821 Harness, Wire, Briggs, M/S
17 344281 Handlebar, Left
18 344291 Handlebar, Right
19 165191 Switch, Snap-In, E/S
20 157201 Key, Ignition Switch
21 191231 Switch, Push/Pull
22 333331 Nut, Nylon Lock, Flanged, 3/8-16
23 A0000253527 Lever, Shift
24 A0000253528 Mount, Lever, Shift
25 180691 Lever, Op Presence W/ Harness
Ref# Part# Description
26 164961 Grip, 1.00"
27 389241 Lever, Cable, Black, Traction Drive
28 351181 Cable, Traction Drive
29 352751 Console, With Label
30 A0000166161 Label, PRO 26
A0000166162 Label, PRO XL30
A0000166156 Label, PRO MAX34
31 111731 Bolt, HCS, Serrated Flange, 5/16-18
X .50"
32 351311 Cable, Shift
33 150361 Knob, PTO Clutch Cable
34 164971 Guard, Switch, Magura
35 352771 Panel, Control, With Label
36 352761 Label, Control Panel, Top
37 363721 Label, Warning
38 363731 Label, Wheel Speed and Throttle
39 151311 Plug, Hour Meter Hole, 2" X 1-1/4"
40 352901 Bolt Shoulder, 1/2" X 5/8"l, 3/8-16
41 150491 Screw 8-32 x 1/2"
42 190031 Plug, Plastic, 1/2" Hole
43 179231 Screw, SHCS, M6 X 25mm
44 363531 Harness, Ground
45 350511 Spacer, Idler
46 112491 Washer, Star, Internal, 3/8", ZP
47 A0000313387 Clamp, Fuel Line
48 265811 Clamp, Vapor Line
49 A0000522190 Hose, Fuel, CA Cert, 16" Long
50 265801 Hose, Vapor, 3/16" ID
