DR Stump Grinder - Parts List - DRIVE ASSEMBLY

26 DR
®
STUMP GRINDER
Parts List – DRIVE ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 11243 Washer, Lock, Split, 5/16"
2 16514 Washer, .385" ID, 1.39" OD, .15"T
3 17882 Bolt, HCS, 5/16-24 X 1", GR2 ZP
4 11158 Bolt, HCS, 5/16-18 X 1", ZP
5 11076 Nut, Nylon Lock, 5/16-18, ZP
6 35087 Bolt, HCS, 5/16-18 X .75", GR 5, ZP
7 33332 Nut, Nylon Lock, Flanged, 5/16-
18
8 35080 Cover, Belt, Inner
9 35248 Cover, Belt, Outer, W/Labels
10 13443 Bolt, HCS, 5/16-18 X 1-1/2", GR5, ZP
11 11241 Washer, Flat, 5/16" USS, ZP
12 11075 Nut, Nylon Lock, 3/8-16, ZP
13 16413 Nut, Nylon Lock, 3/8-16, Lowpro
14 11069 Nut, Hex, 5/16-18, GR2, ZP
15 26483 Ring, Retaining, 1" Shaft
16 14229 Key, Square, 1/4" x 1-1/4"
17 30409 Bolt, Pocket
18 30407 Spacer, Tooth
19 26474 Guard, Pulley
20 25802 Bearing, Stamped Flange, 1" Bore
21 29417 Cutter Head, Dual Straight Green Teeth
22 26565 Pulley, 5" Dia., A/B Profile
23 30406 Tooth
24 30408 Pocket, Straight
25 26535 Bolt, Shoulder, 1/2" X .75"L
26 12686 Bolt, HCS, 3/8-16 x 2", GR5 ZP
27 35072 Arm, Idler Pulley
28 3527 Pulley, Flat, Idler, 3.12" X .75" X .375"
With 3/8" Shoulder Adapter
29 33424 Spring, Idler
Ref# Part# Description
30 34140 Label, Dr Logo Silver, 4" , 4 color
31 27164 Washer, .47" ID, 1.25" OD, .15"T
16514 Washer, .385" ID, 1.390" OD, 3/8" TH
(Premier)
32 22911 Bolt, Hhcs, 7/16-20 X 1", Gr 8, Locking
Patch (Pro and Pro-XL)
17882 Bolt, HCS, 5/16-24 x 1" (Premier)
33 26533 Clutch, Centrifugal, 1" Bore (Pro and
Pro-XL)
26521 Clutch, Centrifugal, 3/4" Bore (Premier)
34 26563 Belt, Stump Grinder (Pro and Pro-XL)
26468 Belt, Stump Grinder (Premier)
35 35426 Spacer, Clutch, 16.5T Engine (Pro-XL)
35425 Spacer, Clutch, 14.5T Engine (Pro)
36 12334 Bolt, HHCS, 3/8-16 x 1.75", GR 5, ZP
(Pro and Pro-XL)
13443 Bolt, 5/16-18 x 1-1/2" (Premier)
37 35064 Engine, B&S, 9.5T, M/S, W/Labels,
Premier
35066 Engine, B&S, 14.5T, M/S, W/Labels, Pro
35068 Engine, B&S, 14.5T, E/S, W/Labels, Pro
35070 Engine, B&S, 16.5T, E/S, W/Labels, Pro
XL
38 11238 Washer, Flat, 1/4"
39 12321 Bolt, HCS, 5/16-18 x 3/4"
40 24677 Key, Square, 3/16" x 1" (Premier)
Not Illustrated
30505 Tooth Kit
18887 Label, Hot Surface
12781 Label, Warning, Check Oil
24677 Key, Square, 3/16" x 1" (Premier)
