DR Stump Grinder - Parts List - AXLE ASSEMBLY

28 DR
®
STUMP GRINDER
Parts List – AXLE ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 19336 Bolt, HCS, 5/16-18 X 1"
2 11243 Washer, Lock, Split, 5/16"
3 11238 Washer, Flat, 1/4"
4 26486 Brake Drum, 4.125" OD
5 24744 Wheel, 14.5 x 7-6, 2 Ply, Gray
6 24677 Key, Sq, 3/16" X 1"
7 12969 Shim, .75"ID X 1.125"OD .06L, ZP
8 11126 Ring, Retaining, 3/4", E
9 16514 Washer, .385" ID, 1.39" OD, .15"T
10 17882 Bolt, HCS, 5/16-24 x 1", GR2 ZP
11 26564 Axle
12 26469 Bushing, Bronze, .75"OD, .63"ID
13 11237 Washer, Flat, 10-24 USS
Ref# Part# Description
14 11073 Nut, Nylon Lock, 1/4-20, ZP
15 11076 Nut, Nylon Lock, 5/16-18, ZP
16 11983 Bolt, HCS, 1/4-20 X 3/4", GR2, ZP
17 26477 Bushing, Flange, .75"ID
18 12336 Bolt, HHCS, 5/16-18 X 1.25",
GR.5, ZP
19 16413 Nut, Nylon Lock, 3/8-16, Lowpro
20 26473 Brake Band
21 25862 Bracket, Battery
22 24230 Strap, Battery, 9ah
23 29379 Tube Clamp, 3/4", Vinyl Coated
24 28697 Pad, Battery, 2.5" X 6.125"
25 14386 Battery Pad
26 13447 Battery, 12v, 9ah
