Preparation
38
Operating Instructions Caleo, Software 2.n
Installing Accessories
Preparing for O
2 therapy with O2 control*
1 Screw the O
2 high pressure supply hose into the port
underneath the incubator. Make sure that it is securely
tightened.
2 Connect quick connect probe to an outlet terminal of your
medical gas pipeline O
2 supply. Use "standby position", if
available (see respective Instructions for Use).
O
2 analyzer
For monitoring O
2 concentration inside the incubator, install an
O
2 analyzer with alarm limits:
z Attach O2 analyzer to rail using the appropriate bracket.
z Place O2 sensor capsule inside Caleo.
z Route sensor cable through one of the flexible hood
grommets. Securely connect sensor plug to O
2 analyzer
(see Instructions for Use of O
2 analyzer being used).
Vacuum mattress (2M 17 909)
The contour of the vacuum mattress can be altered as required
and is maintained after evacuation of the air inside.
This allows to obtain extreme positions for special applications.
The mattress can remain in the incubator.
z Open front door.
z Insert and pre-form vacuum mattress.
z Place infant on mattress and shape mattress around
desired infant position.
z Connect vacuum mattress to the vacuum supply hose of the
suction equipment.
3 Open valve and evacuate vacuum mattress.
3 Close valve and disconnect hose.
z Close front door.
* Available option
CAUTION !
The permissible O
2 inlet pressure is between 300 and
600 kPa (43.5 and 87 psi).
