16 Instructions for use | X-act
®
7000
en | Description
The above trademarks are only registered in certain countries and not
necessarily in the country where this document was published.
3 Description
3.1 Product overview
The scope of supply of the device may be expanded by accessories. The basic
set can be combined with sensors and hoses for remote measurement. This
requires the Dräger X-am pump to be connected using the Dräger X-act 7000
coupler.
3.1.1 Dräger X-act 7000
Graphic A
3.1.2 Basic set
Graphic B
Please observe and adhere to the instructions for use of additional parts, if
provided.
The following components are included in the scope of delivery:
3.1.3 Accessories
Graphic C
The device may be used with the following components for remote and sensor
measurements:
3.1.4 Operation and navigation
The device has three keys. These have been positioned on the device below
the displays which they are used to control (Graphic D/1). Below, these are
referred to as softkeys.
No. Designation No. Designation
1 X-act 7000 7 Holder for coupler
2 Device keys 8 Ring for carrying strap
3 Display 9 Battery cover
4 LED signal light 10 Retainer for Dräger MicroTubes
5 Infrared interface 11 Mini USB port
6 Gas inlet 12 Gas outlet
No. Designation Order number
Basic set: 8610800
1 X-act 7000
2 Dräger MicroTubes Demo 8610290
3 Torx screwdriver (T10) 3712630
4 Carrying strap 8326823
5 Batteries with explosion protection
approval (x5)
3703133
6 Mini USB cable 8318657
7 Instructions for use 9300024
No
.
Designation Order number
1 X-act 7000 coupler 8610810
2 X-am pump 8327100
3 Pre-tube holder 3701985
4 Accessories www.draeger.com
Keys
Used to call up the menu, to navigate down the screen and to control the
left soft key. This key will be referred to as the “DOWN” key.
No. Designation Order number
