6 Dräger X-am 2500
Description
2.2 Intended use
Portable gas detection instrument for the continuous
monitoring of the concentration of several gases in the ambient
air within the working area and in explosion-hazard areas.
Independent measurement of up to 4 gases, in accordance
with the installed Dräger sensors.
Areas subject to explosion hazards, classified by zones
The instrument is intended for the use in areas that are at risk
for explosions in Zone 0, Zone 1 or Zone 2 or in mines at risk
due to black damp. It is intended for use within a temperature
range of -20 °C to +50 °C, and for areas in which gases of
explosion groups IIA, IIB or IIC and temperature class T3 or T4
(depending on the batteries and rechargeable battery) may be
present. For zone 0, the temperature class is limited to T3.
If used in mines, the instrument is only to be used in areas
known to have a low risk of mechanical impact.
Areas subject to explosion hazards, classified by divisions
The instrument is intended for the use in areas that are at risk
for explosions of Class I&II, Div. 1 or Div. 2. It is intended for
use within a temperature range of –20 °C to +50 °C, and for
areas in which gases or dusts of groups A, B, C, D or E, F, G,
and temperature class T3 or T4 (depending on the batteries
and rechargeable battery) may be present.
2.3 Approvals
2.3.1 Marking
Serial no.
1
on separate sticker
2.3.2 Permitted power packs
Power pack 83 22 237;
approved as type ABT 0100
Temperature class T4
–20 °C b Ta b +50 °C
use with alkaline batteries
Duracell Procell MN1500
2
Temperature class T3
–20 °C b Ta b +40 °C
use with NiMH rechargeable batteries
GP 180AAHC
2
(1800 mAh)
or with alkaline batteries
Varta Type 4006
2
Varta Type 4106
2
Panasonic LR6 Powerline
NiMH power pack T4 (order no. 83 18 704);
approved as HBT 0000
Temperature class T4
–20 °C b Ta b +50 °C
NiMH power pack T4 HC (order no. 83 22 244);
approved as HBT 0100
Temperature class T4
–20 °C b Ta b +50 °C
CE marking: Electromagnetic compatibility
(Directive 2004/108/EC)
Explosion protection (Directive 94/9/
EEC)
1 The year of construction is coded by the third capital letter of the
serial number: D = 2012, E = 2013, F = 2014, H = 2015, J = 2016,
K = 2017, L = 2018, etc.
Example: Serial number AREH-0054, the third letter is E, so the
year of manufacture is 2013.
Dräger Safety Type: MQG 0011
23560 Lübeck, Germany
I M1 / II 1G for comb. sensor
I M2 / II 2G Um=4.6V Im=1.3A
Ex ia I/IIC T3 Ma/Ga Ex d ia I/IIC T4/T3 Mb/Gb
BVS 10 ATEX E 080X IECEx BVS 10.0053X
ANZEx 11.2003X PFG 10 G 001X
Intrinsically
safe Ex ia, CSA 11 1800517
CSA:
Class I, Div. 1, Gr. A,B,C,D TC T4/T3
Class I, Zone 0, A/Ex ia IIC T3 /Ga
Class I, Zone 1, A/Ex d ia IIC T4/T3 /Gb
-20°C Ta +50/+40°C: see Battery Pack!
For TC T4/T3: see Battery Pack!
Warning: Read manual for safety precautions.
Do
not change or charge batteries in haz loc.
≤ ≤
0158
C22.2 No.152
C US
