www.dragino.com
LSN50V2-D2x LoRaWAN Waterproof, Outdoor Temperature Sensor 5 / 23
1.2 Specifications
Common DC Characteristics:
➢ Supply Voltage: built in 8500mAh Li-SOCI2 battery
➢ Operating Temperature: -40 ~ 85°C
Temperature Sensor:
➢ Range: -55 to + 125°C
➢ Accuracy ±0.5°C (max ±2.0 °C).
LoRa Spec:
➢ Frequency Range,
✓ Band 1 (HF): 862 ~ 1020 Mhz
➢ 168 dB maximum link budget.
➢ High sensitivity: down to -148 dBm.
➢ Bullet-proof front end: IIP3 = -12.5 dBm.
➢ Excellent blocking immunity.
➢ Built-in bit synchronizer for clock recovery.
➢ Preamble detection.
➢ 127 dB Dynamic Range RSSI.
➢ Automatic RF Sense and CAD with ultra-fast AFC.
➢ LoRaWAN 1.0.3 Specification
Power Consumption
➢ Sleeping Mode: 20uA
➢ LoRaWAN Transmit Mode: 125mA @ 20dBm 44mA @ 14dBm
1.3 Features
✓ LoRaWAN v1.0.3 Class A
✓ Ultra-low power consumption
✓ 1 ~ 3 External Temperature Probes
✓ Measure range -55°C ~ 125°C
✓ Temperature alarm
✓ Bands: CN470/EU433/KR920/US915
EU868/AS923/AU915/IN865
✓ AT Commands to change parameters
✓ Uplink on periodically or Interrupt
✓ Downlink to change configure
1.4 Applications
