Connecting Voltage Measurement Cables
Measurement
cable set
Description: Voltage measurement cables are used to
connect to your circuit via safety banana jack
connectors and alligator clips.
Voltage Rating
: Direct connection of all voltage
measurement inputs are rated at 600 VRMS max.
When measuring voltages greater than 600 VRMS,
potential transformers (PTs) or other transducers must
be used.
Contents
: A cable set consists of four (1 red, 1 yellow,
1 blue, 1 white) 6-foot voltage measurement cables,
each with a detachable alligator jaw safety clip
assembly (maximum jaw opening, 3/4 in (20 mm)).
There are three (3) black and one (1) white safety
clips.
