37
Energy
Description Units Channel (wiring dependent)
True Energy Whr A, B, C
Reactive Energy VArhr A, B, C
Apparent Energy VAhr A, B, C
True Energy (Fundamental) Whr A, B, C
Reactive Energy (Fundamental) VArhr A, B, C
Apparent Energy (Fundamental) VAhr A, B, C

Power
Description Units Channel (wiring dependent)
Frequency Hz A, B, C
RMS Voltage VRMS A, B, C
RMS Current IRMS A, B, C
True Power W A, B, C
Apparent Power VA A, B, C
Reactive Power VAr A, B, C
Power Factor A, B, C
Voltage THD % A, B, C
Current THD % A, B, C
RMS Voltage (Fundamental) VRMS A, B, C
RMS Current (Fundamental) IRMS A, B, C
True Power (Fundamental) W A, B, C
Apparent Power (Fundamental) VA A, B, C
Reactive Power (Fundamental) VAr A, B, C
RMS Voltage (1 sec avg) VRMS A, B, C
RMS Current (1 sec avg) IRMS A, B, C
RMS Voltage (10/12 cycle) VRMS A, B, C
RMS Current (10/12 cycle) IRMS A, B, C
Voltage Phase Deg. A, B, C
Current Phase Deg. A, B, C
