Draper 98678 - Fixed Brush; Patio Cleaner

– 17 –
FIG.
FIG.
FIG.
FIG.22
21
20
19
9.6 FIXED BRUSH - FIGS. 19 - 21
Note: Always make sure the pressure washer is
OFF before swapping nozzles or attachments.
The pressure washer is supplied with a fixed brush
(16). The brush has soft bristles and can be used
in conjunction with the detergent dispenser to
apply detergent to the surface you are cleaning.
These are ideal for cleaning car bodywork,
windows etc. This is a low pressure setting.
The fixed brush requires you to remove the lower
section of the lance, and fit to the upper gun of the
lance as shown.
Note: All these fittings are bayonet fittings which
push in then twist to lock.
9.7 PATIO CLEANER - FIG. 22
Note: Always make sure the pressure washer is
OFF before swapping nozzles or attachments.
The pressure washer is supplied with a patio
cleaner attachment (18). The patio cleaner is ideal
for quick and effective cleaning of large flat areas.
As with the fixed brush the patio cleaner
attachment requires you to remove the lower
section of the lance, and fit to the upper gun of the
lance as shown.
Note: All these fittings are bayonet fittings which
push in then twist to lock.
9. OPERATION
(16)
(18)
