OPERATION Cont’d
- 13 -
DETERGENT SPRAYING
1. Remove the filler cap from the reservoir tank.
See Fig.27.
2. Fill the reservoir with correctly diluted
detergent to the required level See Fig.28 and
refit the filler cap.
3. Switch the machine ‘ON’ See Fig.29.
4. To enable the detergent to flow from the
reservoir tank, pull the nozzle 3 forward
Fig.30.
5. Aim the lance in the required direction and pull
the trigger. Detergent will be syphoned from
the reservoir tank, mixed with water and
sprayed from the lance. To stop spraying
release the trigger to return to standard
pressure washing mode, return the nozzle to the
original position.
Fig.27.
Fig.30.
Fig.29.
3
PW2130 Cont’d
2. Aim the lance spray nozzle in the required
direction See Fig.26.
3. Pull the trigger on the handle. The water will
now spray from the lance. Adjust to the required
spray pattern as shown in Fig. 23 and 24.
To stop spraying release the trigger.
Fig.26.
Fig.28.
