Draytek Vigor2762 - Wall-Mounting the Vigor 2762

8
4
4
.
.
1
1
W
W
a
a
l
l
l
l
-
-
M
M
o
o
u
u
n
n
t
t
i
i
n
n
g
g
t
t
h
h
e
e
V
V
i
i
g
g
o
o
r
r
2
2
7
7
6
6
2
2
DrayTek Vigor 2762 series routers have keyhole type mounting slots on the
underside to hang the router on, using screws attached to a wall or other
surface.
1. A template is provided in the Vigor router packaging box to enable you to
space the screws correctly on the wall
2. Place the template on the wall in the desired position and drill holes through
the cardboard template at the marked points
3. Fit screws into the wall using the appropriate type of wall plug
Note
Recommended drill bit diameter is 6.5mm (1/4”).
4. With the screws installed, the router can be slotted into place
