Vigor2912 Series User’s Guide
4
Interface
Description
PWR
Connecter for a power adapter.
ON/OFF
Power Switch.
USB Connecter for a USB device (for 3G/4G USB Modem or printer).
W1 (Vigor2912) Connecter an ADSL or cable modem for accessing Internet (WAN).
W1 (Vigor2912F) Fiber connection (100Mbps) for accessing the Internet.
W2/P1 Connecter an ADSL or cable modem for accessing Internet (WAN); or
connecter for local network devices (LAN).
This connector is switchable for LAN and WAN connection.
P2~P4 Connecters for local network devices (LAN).
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is
blinking). Press the hole and keep for more than 5 seconds. When you
see the ACT LED begins to blink rapidly than usual, release the button.
Then the router will restart with the factory default configuration.
