Vigor2912 Series User’s Guide
48
When you check IPsec, you will see the following graphic:
Available settings are explained as follows:
Item Description
Profile Name
Type a name for such profile. The length of the file is
limited to 10 characters.
User Name
This field is used to authenticate for connection when you
select PPTP or L2TP with or without IPsec policy above.
The length of the name is limited to 11 characters.
Password
This field is used to authenticate for connection when you
select PPTP or L2TP with or without IPsec policy above.
The length of the name is limited to 11 characters.
Pre-Shared Key
For IPsec/L2TP IPsec authentication, you have to type a
pre-shared key.
The length of the name is limited to 64 characters.
Confirm Pre-Shared
Key
Type the pre-shared key again for confirmation.
Digital Signature
(X.509)
Check the box of Digital Signature to invoke this function.
Peer ID – Choose the peer ID selection from the drop down
list.
Local ID – Choose Alternative Subject Name First or
Subject Name First.
Peer IP/VPN Client
IP
Type the WAN IP address or VPN client IP address for the
remote client.
Peer ID
Type the ID name for the remote client.
The length of the name is limited to 47 characters.
