Dražice OKC 250 NTR - Temperature Setting

- 27 -
3.1.2 TEMPERATURE SETTING
Water temperature is set by turning the thermostat knob. The desired symbol is adjusted against the fixed
point on the control panel (Figure 17).
Figure 17
Adjusting the thermostat knob to the left backstop does not mean permanent shutoff of the
heating element. When the heater is in use without blocking the daily rate, we do not
recommend the temperature to be set above 65℃. Select the "ECO“ symbol as the
maximum.
lower limit of temp. scope
(around 5°C)
fixed point on the control
panel
"anti-freezing" temperature
(about 8°C)
upper temperature range
limit (about 74
℃
)
"ideal" temperature (about
55
℃
)
lower limit of temp. scope
(around 5°C)
"anti-freezing" temperature
(about 8°C)
Fixed mark on the
control panel
upper temperature range
limit (about 80℃)
"ideal" temperature
(about 55
℃
)
