14
EN
❺
Connect the Clean Water Pipe and Controller Assembly
Installation Instruction
1/4" White Clean
Water Pipe (thin)
Ⓝ
1/4" Elbow
(thin)
Ⓕ
Clean Water Pipe
Adapter Assembly
Ⓓ
1/4" Blue Clean Water
Pipe (thin)
Ⓞ
3-Way Diverter Valve
Ⓗ
Controller Assembly
(Solenoid Valve Connector)
Ⓘ
Controller Assembly
(Solenoid Valve Connector)
Ⓘ
1/4" White Clean
Water Pipe (thin)
Ⓝ
