Note:
In order to keep the pipes tidy, use a knife to cut out the appropriate length
of the water pipes before installation.
For other installation methods, please
refer to the following gures:
① Fixed to the Wall Drain
Note:
This part needs to be purchased separately.
② 3-Way Floor Drain Joint
How to Disassemble a Water Pipe
Used Water Pipe
Adapter Assembly
Ⓔ
Snap Ring
3/8" Used Water
Pipe (thick)
Ⓜ
Floor Drain
Hold the snap ring and pull out the
water pipe forcefully.
Installation Instruction
❹
Connect the Used Water Pipe
3/8" Used Water
Pipe (thick)
Ⓜ
3/8" Elbow
(thick)
Ⓖ
3/8" Elbow
(thick)
Ⓖ
Step
❹-❺
To Next Page
