Dreame RAW7 - Page 15

12
EN
Installation Instruction
❹ Connect the Controller Assembly
Install the 3/8" connection locking clip Ⓗ in position ① - ⑦ .
Install the 1/4" connection locking clip Ⓖ in position ⑧ - ⑮ .
❺ Install the Connection Locking Clip
How to Disassemble a Water Pipe
Hold the snap ring and pull out the
water pipe forcefully.
Snap Ring
②
⑨
⑩
⑪
⑫
⑬
⑭
⑮
③
④
⑤
⑥
⑦
① ⑧
