Dreame RAW7 - Page 14

11
EN
Installation Instruction
❷ Connect the Used Water Pipe
Water
Source
1/4" Elbow
(thin) Ⓒ
1/4" White Clean
Water Pipe
Ⓜ
1/4" Elbow
(thin) Ⓒ
Controller Assembly
(Solenoid Valve
Connector)
Ⓔ
1/4" Blue Clean
Water Pipe
Ⓝ
One-way Valve
Assembly Ⓕ
3/8" Used Water
Pipe
Ⓛ
3/8" Elbow
(thick) Ⓑ
3/8" Elbow
(thick) Ⓑ
3/8" Used Water
Pipe
Ⓛ
Floor Drain
❸ Connect the Clean Water Pipe
Note: If you choose the installation of 󶀄xing to the wall drain, the height of the used water outfall should be ≤ 100cm.
