Dreame RAW7 - Page 13

10
EN
Installation Instruction
4. Insert the two pipes from the position ① to position ② , and insert them to
the end.
3. Use a screwdriver to loosen the 󶀄xing screws on the back cover of the base
station, store the cover properly.
Cut o󶀃 a certain length ( ≥ 18cm) of the clean water pipe Ⓜ and used
water pipe Ⓛ .
Clean Water
Pipe Ⓜ
Clean Water
Pipe Ⓜ
Used Water
Pipe Ⓛ
Used Water
Pipe Ⓛ
≥ 18cm
①
②
