14
EN
Installation Instruction
Option 2 - Water Source with Female Thread Fitting
Angle Valve/Water Source
(
not supplied
)
Faucet/Plug3-Way Diverter
Valve
Ⓓ
Blue Clean Water Pipe
(
from controller assembly
) Ⓝ
