Mandrel No. 401 is used with the felt
polishing tip and wheels. Thread the tip on to
the screw carefully. The felt tip must thread
down straight on the screw Mandrel, and be
turned all the way to the collar.
Mandrel N° 402 has a small screw at its tip,
and is used with emery cutting wheels and
sanding discs. Higher speeds, usually
maximum, are best for most work, including
cutting steel. Which is shown here.
To replace a band on the Drum Sander,
loosen the screw without removing it to
contract the drum then slide the old band off.
Slide the new sanding band on and then
expand the drum by tightening the screw
once again.
Before each use, check to
make certain that all
components are assembled to accessory
shank and that the drum is sufficiently
expanded to secure the band during use.
If sanding band is loose on the drum during
operation it may “fly” off and strike you or
bystanders.
!
WARNING
