Battery tools are always in an operative condition. Be aware of the
possible hazards.
SAVE THESE INSTRUCTIONS
-9-
Functional Description and Specifications
!
WARNING
Stylus
™
Cordless Rotary Tool
FIG. 1
DREMELDREMEL
CHARGE
INDICATOR
LIGHT
CHARGER
ON/OFF
BUTTON
SHAFT LOCK
BUTTON
SPEED
CONTROLLER
VENTILATION
OPENINGS
COLLET NUT
COLLET
ACCESSORY
STORAGE
WRENCH
STORAGE
Rotary Tool
Model number 1100
Voltage rating 7.2 V
No load speed n
o
5,000-25,000/min
Collet Capacities 1/32", 1/16", 3/32", 1/8"
Charger
Model number 866
Voltage rating
120 V 60 Hz
Amperage rating 375 mA
Charge time 3 Hr.
SIDE CAR FOR EXTRA TOOL
STORAGE
(Included in model 1130 only)
