Front Grille and Blades
To reduce the risk of electrical shock and injury
to persons, turn off and unplug the appliance
before any cleaning and maintenance.
WARNING
1
Remove the screw on the front grille,
rotate the grille counterclockwise to
take it off.
Remove the blade cap by rotating it
as shown and take the blade
assembly out of the shaft.
5
Align the point on the front grille with the
right point on the casing as shown, then
rotate the grille clockwise and install the
screw back in place.
Rinse cap, blades, and grille under
running water or with a clean, damp
cloth.
4
Dry up all parts, and insert the
blade assembly back into the
shaft by aligning the centers.
