DRIFT HD Ghost User Manual

13
the two-way remote control
Powering on and o
1. Ensure the camera is powered on (see p5)
2. Press and hold the @ ACTION button on the remote—the LED will power on
and indicate the current camera mode
! The remote will automatically power o if it does not find a camera after 15s
Charging
Connect the remote control using the Mini USB cable (provided) to a powered
USB port. The LED will blink red. A full charge takes around 2 hours using a 2
amps charger. Once the remote is fully charged, the LED will show solid green—
remove the mini USB cable and replace the rubber dust-proof USB seal.
Pairing camera to a remote control - one to one
[The camera and remote control included in the package are already paired to
one another]
1. On the camera, press MENU, select Camera Settings from the Main Menu and
press ACTION
2. Highlight ‘Remote Pairing’ on the Camera Settings menu and press ACTION
3. On the remote control, press @ ACTION—The camera will beep and return to
the Camera Settings menu if it has recognised the remote
! If the camera does not display ‘successful’ and return to the Camera Settings
menu it will not be paired—try pressing @ ACTION on the remote again
4. On the camera, the icon beside Remote Pairing will change to indicate it is
paired to a remote control
Using the remote control - one to one
While the camera and remote are both powered on and paired, pressing @ACTION
on the remote control will begin recording video, capture a photo, start
timelapse or photoburst, depending on the camera mode.
Pressing @ ACTION while recording video will capture a photo, or start Video
Tagging (if activated, see p7). Pressing STOP will end video recording or timelapse.
Pressing STOP while the camera is in Live Preview will toggle between camera
modes, as indicated by the LED indicator on the camera and remote (see over)
ACTION Button
STOP Button (Tag/Toggle Mode)
LED Indicator
! The Remote is NOT waterproof.
! The Two Way Remote and the App
CANNOT be used simultaneously.

DRIFT HD Ghost Specifications

General

Video resolutions	1280 x 720, 1280 x 960, 1920 x 1080 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 720p, 960p
Video formats supported	H.264, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Photo mode	Yes
Sensor type	CMOS
Light exposure modes	Auto, Manual
Display diagonal	2 \
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Internal memory	0.256 GB
Compatible memory cards	microSD (TransFlash), microSDHC
Maximum memory card size	32 GB
GPS (satellite)	No
Product color	Black
Protection features	Water resistant
Battery voltage	3.7 V
Battery capacity	1700 mAh
Battery life (max)	- h

Weight and Dimensions

Depth	33 mm
Width	52 mm
Height	105 mm
Weight	167 g
