REPLACEMENT PARTS
Table 17-1: VAPORMIST
®
(see drawing on Page 16)
* Specify humidifier model and serial numbers when ordering.
NOTE: More replacement parts are listed on the next page.
No. Description Qty. Part No.
1 Head bolt, large Phillips, ¼ - 20 x 1" 4 700300-013
2 Thermo cut-out 1 409560-001
3 Cover, heater terminal 1 *
4 Hose clamp, 2" ID 2 700560-200
5 Hose cuff, 1½" ID, VM 2-16 1 305390-006
5 Hose cuff, 2" ID, VM 21-34 1 305391-006
6 Cover, tank 1 *
7 Heater element * *
8 Probe assembly cord and plug 1 406050-005
9 Probe assembly gasket 1 309750-004
10 Probe assembly, VM 2-4 1 406270
10 Probe assembly, VM 6-34 1 406275
11 Valve, ¾" electric, 24V, VM 2-34 1 505400-001
11 Valve, ½" SST ball, VMDI 2-34 1 505000-003
11
Drain, ¼" NPT E.O.S., 24V solenoid SST w i t h DIN
plug (not shown), VMDI 2-34 w/EOS drain
1 505086-003
12 Tank weldment 1 *
13 Valve, ¼" solenoid, 24V w i th DIN plug 1 505084-001
14 Cabinet enclosure 1 330-000-001
15 Hose, ¾" ID 1 307020-002
16
Hose clamp, ¾" ID 4 700560-075
