REPLACEMENT PARTS
Table 17-1 continued: VAPORMIST
®
(see drawing on page 16)
* Specify humidifier model and serial numbers when ordering
No. Description Qty. Part No.
17 Nut assembly, ¼-20, VM/VMDI 2-4 4 700650
17 Nut assembly, ¼-20, VM/VMDI 6-34 2 700650
18 Gasket, tank cover 1 *
19 Washer, #8 external tooth, plated 2 700200-003
20 Nut, #8-32 hex, plated 6 700200-002
21 Cover, subpanel 1 120277
22 Fill adapter, VM 2-4 1 160226-041
22 Fill adapter, VM 6-16 1 160224-041
22 Fill adapter, VM 21-34 1 160224-052
23 Panel, insulation 1 309845-003
24 Sensor, temperature 1 405760
25 Screw, Phillips head, #8-32 x ½" 8 700170-007
26 Frame assembly, chassis 1 165541
27 Clip, wire harness 1 405892-001
28 Clip, temperature sensor 1 408251
29 Valve assembly, float 1 505310
30 Switch, float, 1/8" NPT 1 408420-002
31 Gasket, 2.50 OD X 1.90 ID 1 309750-004
32 Seal ring, ¼"-18 NPT 1 306365
33 Gasket, bulkhead, 1.60 OD X 1.15 ID 1 309750-005
34 Probe housing, nylon, VM 1 308500
35 Nut, VM heater .475 dia 1 409601-001
36 Gasket, VM heater .475 o-ring, 5/8" EPDM #016 1 300400-009
37
Cap, black 4 409593-002
