Operating the AquaJoy VALU£ in the bath
1. Before using your bathlift, make sure that the
hand control is connected properly via the plug-
type connection on the bathlift. The red ring at
the jack is now unseen. Press the ON button
(green) on the hand control. The green control
lamp is illuminated.
2. Now press the UP button (yellow). The back-
rest moves to an upright position first; then
the lift rises to its end position and switches
off automatically. The lift can be raised to any
height in between, by releasing the button once
the required height is achieved.
3. Fold out the side flaps until they rest on the
sides of the bath. Raise the seat until the seat
surface is at the same level as the upper edges of
the bath and the side flaps are in a horizontal
position
Important: The side flaps must rest flat on
the
side surfaces of the bathtub.
4. Sit down on bathlift. If this is not possible
without help, ask for assistance.
5. To lower bathlift, press the Down button (blue).
The lift lowers until it reaches its end position,
then the backrest is tilted back automatically.
The drive switches off automatically in the end
position. However, the backrest can be rec- lined
to an angle in between by simply releasing the
button once the required angle has been
achieved.
Attention: if the backrest pushes against the
wall of the bath release the blue button
immediately!
