Technical Data AquaJoy VALU£ bathlift
Overall length (with backrest in a reclined position) approx. 830 mm (32.7 in)
Overall width (seat incl. side flaps) approx. 700 mm (27.6 in)
Width of seat approx. 350 mm (13.8 in)
Depth of seat approx. 420 mm (16.5 in)
Overall length of seat approx. 570 mm (22.4 in)
Sitting height min. approx. 60 mm (2.4 in)
Sitting height max. approx. 480 mm (18.9 in)
Height of backrest approx. 640 mm (25.2 in)
Width of backrest approx. 320 – 360 mm (12.5 – 14.2 in)
Backrest adjustment 10° – max. 50°
Width of baseplate approx. 310 mm (12.2 in)
Length of baseplate approx. 560 mm (22.1 in)
Load capacity max. 140 kg
Total weight (excl. hand control) approx. 9,3 kg (20.5 lb)
Total weight (incl. hand control) approx. 9,7 kg (21.4 lb)
Weight of hand control incl. battery approx. 0,4 kg (0.88 lb)
Weight of drive unit approx. 3,8 kg (8.37 lb)
Weight of seat unit approx. 5,5 kg (12.1 lb)
Duration of lifting/lowering movement, each approx. 50 seconds under load
Operating voltage 12 V
Storage battery (lithium-ion) 12 V / 1,3 Ah re-chargeable
(see designation on housing)
Automatic shutdown max. 30 minutes
Power input 90 W max. 12 V
Type of application part (B)
Protection class IP X7
Power to push the button of the hand control 3 N
General Operating Conditions
Ambient conditions for operation:
