9 . S P E C I F I C AT I O N
SPECIFICATIONS
Model
PHOENIX HD 3
PHOENIX HD 4
Dimension
(L x W x H mm)
(L x W x H inch)
980×550×1010mm
(38.5"×21.7" ×39.7")
1055×550×965mm
(41.5"×21.7" ×38.0")
Base Weight
30.3kgs / 66.6lbs
35.3kgs / 77.6lbs
Battery Weight
13.8kgs / 30.6lbs
13.8kgs / 30.6lbs
Seat Weight
10.8kgs / 23.8lbs
10.8kgs / 23.8lbs
Total Weight
55kgs / 121lbs
60kgs / 132lbs
Controller
CTE STAR 70A
Battery
12V 20AH x 2
Charger
HP 2A OFF BOAD (HP-1202B)
Front Tire
200×50mm / 7.8” ×2.0” solid
230×75mm / 9.0” ×3.0” solid
Rear Tire
230×75mm / 9.0” ×3.0” solid
Driving System
Direct rear wheels (with differential gear)
Brake System
Electromagnetic brake
Control Method
By speed control lever
Top Speed
6.4km/hr / 4 mph
Climbing angle
8°
Cruising range (see note)
19km / 12 miles
Max. User weight
160kg / 350lbs
Remark: The manufacturer reserves the right to modify the specification if necessary. The
final specification is subject to the individual scooter you purchase from your dealer.
Note: Maximum driving distance is based on an ambient temperature of 20C, a 75kg
driver and a brand new fully charged battery by a constant driving speed at 6 km/h with
70% battery power discharged.
