Instruction BookletST-3
13
Remove Front Basket (G) by lifting.(See Fig. 8)
Rotate Hand Wheel Tiller Angle Adjustment (H) counterclockwise to adjust tiller down.
Rotate Wheel clockwise to lock tiller.(See Fig. 9)
Figure 8Figure 8 Figure 9Figure 9
Pictured are 5 main parts after disassembling scooter. These parts consist of Front and
Rear Sections, Seat, Basket, and Battery pack.(See Fig. 10)
Figure 10Figure 10
(G)
(H)
