Instruction BookletST-3
12
DISASSEMBLING YOUR SCOOTER
Taking apart your scooter enables you to save space when keeping it in storage or to carry
it along in your vehicle when going away from home. No tools are reguired to disassemble
the scooter. Please follow these steps:
Remove seat by pulling up Seat Rotation Lever (A). Then lift the seat up from scooter.
(See Fig. 4)
Push Release Lever (B) backward and pull Battery Pack Handle (C) to re-move batteries
from scooter. Caution: batteries are heavy. When lifting please use correct lifting posture
to avoid injury. Ask for assistance if necessary.(See Fig. 5)
Figure 4Figure 4 Figure 5Figure 5
Hold Seat Receiving Post (D) and push the Release Lever (E) backward to unlock battery
pack.(See Fig. 6)
Hold Seat Receiving Post (F) and lift up front section. Front and rear sections can be
separated.(See Fig. 7)
Figure 6Figure 6 Figure 7Figure 7
(A)
(C)
(D)
(F)
(E)
(B)
To Next Page
