Drive Trident - Electrical Components Identification

Trident Owner’s Manual www.drivemedical.com
15
Please refer to the diagram below to identify your power wheelchair electrical
components. Familiarize yourself with the terminology to better understand
references throughout the Owner’s Manual.
1. Controller
2. Keypad Overlay
3. Charger Input
4. Controller Harness
5. Power Module
6. Left Motor
7. Left Motor Harness
8. Right Motor
9. Right Motor Harness
10. Battery 1
11. Battery 2
12. Circuit Breaker
13. In-Line Fuses
14. Battery Harnesses
V. PARTS
