XI. BASIC TROUBLESHOOTING
The diagnostic flash codes for your power wheelchair are designed to help you
perform basic troubleshooting quickly and easily. A diagnostic flash code can be
displayed in one of two ways:
 A small wrench will flash under the horn button a certain number of times
indicating the diagnostic code
OR
 The number of battery gauge lights flashing indicates the diagnostic code
Please refer to the diagram below for flash codes, description of problem, and
recommended actions.
Flash Code
Description
Recommended Action
1
Battery Fault
Charge batteries. Check battery cables and connections.
2
Left Motor Fault
Check motor connections and leads between left motor
and power module
3
Left Motor
Wiring
Check all connections and leads between left motor and
the battery.
4
Right Motor
Fault
Check motor connections and leads between right motor
and power module.
5
Right Motor
Wiring
Check all connections and leads between left motor and
the battery.
6
Charger Inhibit
Disconnect the battery charger from the controller.
7
Joystick Fault
Make sure the joystick is in the center position before
powering on the power wheelchair.
8
Power Module
Fault
Check all electrical connections and leads for a secure
connection.
9
Park Brake
Fault
Put the freewheel levers in “drive” mode. Check parking
brake connections.
10
Battery Fault
Excessive battery voltage, check all connections.
Once the recommended action is taken, turn the power wheelchair off and then back
on again to clear the flash code. If the problem was not corrected, or another problem
exists the controller may display another flash code.
