19
4) Program operation acceleration/ deceleration time selection.
The acceleration/ deceleration time for code numbers 55-62 can be selected from among the following four
choices:
(1) Acc1/ Dec1 [Acceleration (1)/ deceleration time (1)]
(2) Acc1/ Dec1 [Acceleration (2)/ deceleration time (2)]
(3) Acc1/ Dec1 [Acceleration (3)/ deceleration time (3)]
(4) Acc1/ Dec1 [Acceleration (4)/ deceleration time (4)]
5) Acceleration/ deceleration time setting
Acceleration/ Deceleration time Setting item
Acc1/ Dec1
08 Accl.Time (acceleration (1) time is set)
09 Dec1.Time (deceleration (1) time is set)
Acc2/ Dec2
80 Acc2.Time (acceleration (2) time is set)
81 Dec2.Time (deceleration (2) time is set)
Acc3/ Dec3
82 Acc3.Time (acceleration (3) time is set)
83 Dec3.Time (deceleration (3) time is set)
Acc4/ Dec4
84 Acc4.Time (acceleration (4) time is set)
85 Dec4.Time (deceleration (4) time is set)
Table 9 Acceleration/ deceleration time setting
Code No. / indication Function Selection Input signal
No. 63 Ref.F.sel
Frequency setting operation place
selection
Dir/ Rem
The DIR/REM keys at the console are used to switch between the console and
terminal.
Terminal
(33) - (34) voltage at the terminal is applied.
(35) - (34) current at the terminal is applied.
Console The reference frequency set in code No.00 Ref(set).F at the console.
Option-1 Signal from the optional board.
Option-2 Not used (reserved for function extension)
Up/ Down Key Acceleration/ deceleration operation using the UP/ DOWN keys at the console.
Up/ Down Term
Acceleration/ deceleration operation by opening/ closing the multifunction
terminal input 2 contact.
No. 64 START-SW.Sel Start switch operation place selection
Dir/ Rem
The DIR/ REM keys at the console are used to switch between the console and
terminal.
Terminal
(17) - (18) START.F, (19) - (18) START.R, (20) - (18) JOG-F, and (21) - (18)
JOG-R contacts at the terminal.
No. 65 JOG-SW-Sel Jog switch operation place selection
Console The FOR/ REV, START/STOP, and JOG keys at the console are used.
Option-1 Signal from the optional board.
Option-2 Not used (reserved for function extension)
Table 10 Operation place selection
4-2-14 Operation place selection
The operation place for frequency setting, start switch operation, and jog switch operation can be selected from
among the console, terminals, optional board, UP/DOWN keys, and multifunction terminal input.
